Piping and Stress

With our experience in design consultancy, we are well aware of the multiple targets a designer has to meet during the development process. We have a proven track record in providing efficient and practical solutions to optimise any design for crucial design criteria such as strength, reliability, simplicity, weight and cost.

With our background in CAD modelling as the foundation, we have over 20 years of experience in the area of stress analysis and FEA modelling.

Contact our team
pipework and stress

Bespoke Solutions

Within our Piping, Vessel and Stress departments we utilise industry standard software packages in delivering solutions and analysing problems:

  • Static Stress
  • Fatigue and Life Prediction
  • Pressure Vessel Design
  • Pipework Stressing
  • Steel Structures
  • Composite Materials
  • Contact Situations
  • Dynamic Analysis
  • Vibration and Resonance
  • Shock and Impact
  • Seismic Loads
  • Non-Linear Stress
  • Drop Test Simulation
  • Snap-Fit Assemblies
  • Heat Transfer
  • Thermal Stresses
  • Fluid Dynamics
  • Air Flow in Compartments
  • Free and Forced Convection
Get In Touch
pipeworks

Range of Software

OLG employs the software listed below to guarantee that all of our work adheres to the high standards we’ve established:

  1. AutoCAD Plant 3D – Integrated 3D plant design engineering CAD software tools for the design and modelling of process, power, industrial, and manufacturing facilities.
  2. CAESAR II evaluates the structural responses and stresses of piping systems to international codes and standards.
  3. FE/Pipe is a complete and full-featured FEA package for the pressure vessel and piping systems. It allows On Line Design to analyse individual or multi-component geometries to consider the interaction between multiple nozzles, saddles, clips, lugs, bends, etc.
  4. NozzlePRO is a single-component analysis tool for piping and pressure vessels.  Analyse individual nozzles, clips, lugs or saddles.
  5. PV Elite performs calculations in accordance with ASME Section VIII Divisions 1 & 2, PD 5500 and EN 13445. Rules from API579 (Fitness for Service) are also included for evaluating the current state and remaining life of existing vessels.
  6. Finglow, Engineering Software for the Design of Pressure Vessels and Heat Exchangers.in accordance with all the leading international codes of practice, including ASME VIII Divisions 1 & 2, PD 5500,  Stoomwezen and EN 13445.
  7. Navisworks – used for model simulations and model reviews.
Contact our team
